Thetransducersshouldbeinstalledawayfromanyprotrusionssuchas
othertransducers,steps,ribs,strak es,orrowsofrivets.
Transducersshouldbeinstalledinalocationwherenoloadwillbeapplied
tothetransducersduring,launching,lifting,traileringandstorageofthe
boat.
Transducersmustbeinstalledinthecorrectorientation,withthe
anti-rotationboltclosesttothesternofthevessel.Additionally,adirection
arrowpointingtothebowisembossedontheanti-rotationboltcap.
Wheninstallingsplit-pairtransducers:
thecorrecttransducer(portorstarboard)mustbeinstalledinthe
matching(portorstarboard)sideofthehull.Thetransducershavelabels
onthetopfacethatidentifywhichsidetheyshouldbeinstalledonand
thetransducer’selementangle:
1.Directiontovesselbow
2.Elementangleandvesselside:
Single(all-in-one)transducersaremark
ed“0°”
Splitpair(“12°”or“20°”)
Splitpairport,“P”orstarboard,“S”)
3.SplitpairVesselsideanddirectiontovesselkeel(Singleall-in-one
transducersdonotincludethislabel.)
eachtransducerinasplitpairhavelabelsonthetransducercablesand
alsolabelsontheaccompanying‘Y’cablewhichidentifytheside:
1.GreenStarboard-sideYcable.
2.GreenStarboardsidetransducercable.
3.RedPortsideYcable.
4.RedPortsidetransducercable.
choosemountingpositionsthataresymmetricaboutthecenterlineof
thevessel.
choosemountingpositionsthatareatleast300mm(12inches)below
thewaterline.
Transducersshouldbeinstalledinalocationwherethereissufficient
clearanceinsidethehulltofitthenutandhaveatleast100mm(4in)of
headroomtoallowforwithdrawal.
Toavoidinterferencewiththeinternalmagnetometer,mounttransducers
atleast1m(39inches)fromotherelectricaldevices.
Coredfiberglasshullmounting
Itisrecommendedthatthetransducerismountedinanon-coredsection,if
installationinacoredsectionisrequiredthentheareaaroundtheholemust
beadequatelystrengthenedtoensureitisnotdamagedwhentightening
thehullandanti-rotationnuts.
Important:
Installationinacoredfiberglasshullshouldonlybecarriedoutbya
competentmarineinstaller.
L ocationrequirements
23
