6.T
ransducer,e.g.:RVM-412Port.
7.Transducer,e.g.:RVM-412Starboard.
•ForcompatibleMFDandsonarmodules,referto:
p.14—Compatiblesonarmodulesanddisplays
•Fordetailsonextensioncables,referto:
p.37—RealVision™Max3Dtransducerextensioncables
9.5RealVisiontransducerextensioncables
Y ourtransducerissuppliedwithafittedcable,forsomeinstallations
(includingallsplit-pairtransducerinstallations)itmaybenecessarytoextend
thelengthofthetransducercable.
Note:
•Forbestperformance ,cablerunsshouldbekepttoaminimum.
•OnlyuseRaymarine®transducerextensioncables.
R aymarine®offershefollowingoptionalextensioncablesareavailable:
•RealVision™transducerextensioncable3m(9.8ft)(partnumberA80475)
•RealVision™transducerextensioncable5m(16.4ft)(partnumberA80476)
•RealVision™transducerextensioncable8m(26.2ft)(partnumberA80477)
Splitpairtransducers:Extensioncablesfittedbetweenthetransducerand
the‘Y’cablemustbefittedinequallengthpairs(i.e.:eachtransducer’sfinal
cablelengthmustbethesame).
Warning:Maximumtransducercablelength
ThemaximumlengthofcablebetweenaRealVision™Max
3DtransducerandaMFD/sonarmodule(includingthe
transducer’scaptivecable)mustNOTexceed18m(59ft).
Cablelengthsgreaterthanthismaycausedamagetothe
RealVision™Max3DtransducerandMFD/sonarmodule.
9
.6Makingconnections
FollowthestepsbelowtoconnectthetransducercabletoaRealVision™Max
3Dsonar-capabledevice(i.e.:Axiom™2ProMFDorRVM1600sonarmodule).
1.Ensurethatthevessel'spowersupplyisswitchedoff.
2.Connectcablesasfollows:
i.ConnectthecablefromeachtransducertotheY-cabletails(A80478);
checkthecoloredlabelsonthecablestoensurethatthetransducers
areconnectedtothecorrectY-cabletail.
ii.ConnectanextensioncabletotheremainingfreeplugontheY-cable.
Seep.37—RealVision™Max3Dtransducerextensioncables.
3.Ensuringcorrectorientation,pushthetransducercable(orextension
cable)connectorfullyontothecorrespondingconnectoronyourMFD
orsonarmodule.
4.Turnthelockingcollarclockwisetosecurethecable.
