5.
1TransducerdimensionsRVM-4xx
Thedimensionsrelevantforinstallationareshownbelow.
AlltransducersintheRVM-4xxserieshavethesameexternaldimensions.
Item
Dimension
A
60 .00mm(2.36in)
B
42.00mm(1.65in)
C
35.00mm(1.40in)
D
101.50mm(3.99in)
E
8.00mm(0 .31in)
F
170 .60mm(6.72in)
G
53.10mm(2.10in)
H
85.00mm(3.35in)
I
68.00mm(2.68in)
J
14.90mm(0 .59in)
K
424.69mm(16.72in)
L
79 .64mm(3.14in)
Nutsizes
Hullnut68mm(2¾in)acrossflats
Anti-rotationnut13mmin)acrossflats
T
ransducercablelength
Thelengthofthecablefittedtothetransduceris:
RVM-4008m(26.2ft)
RVM-412andRVM-4202m(6.5ft)
RealVisiontransducercableconnectordimensions
Thedimensionsofthetransducercableandcableconnectorareshown
below.
Cableconnectordimensions
Item
Dimension
A
32.00mm(1.26in)
B
25.00mm(1.00in)
C
96.00mm(3.80in)
D
Cablelength:
Single(All-in-one)transducerfittedcablelength:8m(26.2
ft).
Splitpairtransducerfittedcablelength:2m(6.5ft).
Productdimensions19
