3.Carefullyinsertthepointedendofthesuppliedtoolintothesplit-ring’
s
gap(labelled‘C’intheillustration).Usethetooltogentlyleverthesplit
ringoverthemouldingontheconnectoruntilitsnapsintoposition
approximately0.5cmfurtherbacktowardsthecable-endofthe
connector.
Alwaysusethesuppliedtoolwhenattachingthesplitring.Thesplitring
maybecomeoverstretchedandbreakifyoutrytoattachitwithoutusing
thetool.Asparesplitringissuppliedwiththelockingcollarassembly,
incaseofbreakage.
4.SlidetheO-ring(arrowed)overtheendoftheconnector,andensure
thatitisseatedsquarelyagainsttheconnectormoulding,adjacentto
thesplit-ring.
5.Slidethelockingcollartowardstheplug-endoftheconnector,rotating
thecollarasnecessarytoensurethatthelugsonthelockingcollar
(labelled‘D’intheillustration)passthroughthechannels(labelled‘E’)
inthesplit-ring.
Thelockingcollarslideseasilytowardstheplug-endoftheconnector,
beforebuttingupagainstthesplit-ringmoulding.
6.Graspthebodyoftheconnectorwithonehand,thenwiththeotherhand,
pullthelockingcollarfirmlytowardstheplug-endoftheconnector.
Asyoupullthelockingcollar,itclicksintoplaceoverthesplit-ring.The
lockingcollarstaysinpositionontheconnector,butrotatesfreely.
9.3RVM-400connection
Theall-in-onetransducercanbeconnecteddirectlytotheMFDorsonar
module.
1.Optionalright-angledadaptor(A
80515),suppliedseparately(usedto
reducethespacerequiredbehindanMFD).
2.CompatibleMFDorsonarmodule.
3.Transducer.
4.Toextendthecablerun,optionalextensioncablescanbefittedbetween
thetransducerandtheMFDorsonarmodule.
•ForcompatibleMFDandsonarmodulesreferto:
p.14—Compatiblesonarmodulesanddisplays
•Fordetailsonextensioncablesreferto:
p.37—RealVision™Max3Dtransducerextensioncables
9.4RVM-412/RVM-420connection
SplitpairtransducersareconnectedtotheMFDorsonarmoduleusingthe
supplied‘Y’cableandextensioncable.
1.CompatibleMFDorsonarmodule.
2.Optionalrightangledadaptor(A80515)suppliedseparately(usedto
reducethespacerequiredbehindanMFD).
3.‘Y’cable(supplied)
4.8m(26.2ft)extensioncable(supplied)
5.Optionalextensioncablescanbefittedbetweenthetransducerand
‘Y’cableifrequired,orbetweensuppliedextensioncableandMFDor
sonarmodule.
