4.
1Partssupplied—RVM-4xxseriestransducers
ThefollowingpartsaresuppliedwitheachRVM-4xxseriestransducer.
Item
Description
1Documentationpack
2
L ockingcollarkit(fortransducercableconnector),consistingof:
•2xSplitrings(includesspare)
•1xO-ring
•1xLockingcollar
•1xSplitringfittingtool
3
Hullnut
4
Cableprotector
5L argeinternalisolatorsleeve
6
Rubberwasher
7Externalisolatorplate
8
Highspeednosecone
Item
Description
9
T
ransducer(includingfittedcable—refertolengthstated
below)
102xNutsforanti-rotationstuds
11
2xSmallwashersforAnti-rotationstuds
122xSmallinternalisolatorsleeves
132xExternalisolatorsleeves
Transducercablelength
Thelengthofthecablefittedtothetransduceris:
•RVM-400—8m(26.2ft)
•RVM-412andRVM-420—2m(6.5ft)
Additionalpartssupplied
Thefollowingadditionalcablesaresuppliedwhenorderingasplitpairsetof
transducers.
Item
Description
1
2xLockingcollarkit,consistingof:
•2xSplitrings(includesaspare)
•1xO-ring
•1xLockingcollar
•1xSplitringfittingtool
2
Extensioncable8m(26.2ft.)forconnectingthesingleendof
the“Y-cable
”adaptertoacompatibleMFDorsonarmodule.
3“Y-cable”adapterforconnectingasplitpairoftransducerstoa
singleextensioncable.Cablelength:0.3m(0.98ft.)
P artssupplied
17
