ealVision™Max3Doverview
RealVision™Max3Dtransducersofferthefollowingrangeofimprovements
overRealVision™3Dtransducers:
•Improvedpingratesandtighterbeamwidths,resultinginsharpersonar
images,detailedwrecks,anddistinctfishtargets.
•HigherresolutionDownVisionandSideVisionimaging,combinedwith
highercontrastcolorpalettes—makingiteasiertoidentifystructure,and
allowingfishtargetstostandoutfromthewatercolumnnoise.
•Moreaccuratetargetlocationcapability,makingiteasiertopinpointthe
positionofawreckorsetupadrift.
•New600WHighCHIRPfrequencyprovidesdeepertraditionalsonar
rangeandstrongertargetreturns.
RealVision™3DMaxscreenexample
Sonarrange
Thesonarrangeistheeffectivedepthordistancethatthetransducercan
operateto
,inoptimumweatherconditions.
ThefollowingrangesapplytoRealVision™Max3Dsonarchannels:
Note:
Thelistedsonarchannelrangesareindicativeonly
,andaresubjectto
changedependingupontheconnectedtransducer.
Sonarchannel
R
ange
CHIRPsonar:
0
.6m(2ft)to366m(1,200ft)
Down
Vision™:
0.6m(2ft)to183m(600ft)
SideVision™:
0.6m(2ft)to91m(300ft)
RealVision™Max3D:
0.6M(2ft)to91m(300ft)
Compatiblesonarmodulesanddisplays
Transducersmustbeconnectedtoacompatiblesonarmoduletointerpret
andtransmitthesonarimagetoadisplayscreen.Thesonarmodulemaybe
externalorinternal(built-in)tothedisplay.
Y ourtransduceriscompatiblewiththefollowingsonarmodules:
•Axiom™2ProrangeofMFDs,whichincludeacompatibleinternalsonar
module.
•RVM1600RealVision™Max3Dexternalsonarmodule.
Note:
ThetransducerisNOTcompatiblewiththeRVX1000RealVision™3D
externalsonarmodule,ortheinternalsonarmodulesbuilt-intoAxiom™,
Axiom™+andAxiom™ProMFDs.
RealVisiontransducerextensioncables
Y ourtransducerissuppliedwithafittedcable,forsomeinstallations
(includingallsplit-pairtransducerinstallations)itmaybenecessarytoextend
thelengthofthetransducercable.
Note:
•Forbestperformance,cablerunsshouldbekepttoaminimum.
•OnlyuseRaymarine®transducerextensioncables.
Raymarine®offershefollowingoptionalextensioncablesareavailable:
•RealVision™transducerextensioncable3m(9.8ft)(partnumberA80475)
