Raymarine RVM-400 Series User Manual

CHAPTER1:IMPOR
TANTINFORMATION
Safetywarnings
W
arning:Productinstallationandoperation
•Thisproductmustbeinstalledandoperatedinaccordance
withtheinstructionsprovided.Failuretodosocouldresult
inpersonalinjury
,damagetoyourvesseland/orpoor
productperformance.
•Raymarinehighlyrecommendscertifiedinstallationby
aRaymarineapprovedinstaller.Acertifiedinstallation
qualifiesforenhancedproductwarrantybenefits.
RegisteryourwarrantyontheRaymarinewebsite:
www.raymarine.com/warranty
Warning:Highvoltage
Thisproductcontainshighvoltage.DoNOTremovecovers
orattempttoaccessinternalcomponents,unlessspecifically
instructedinthedocumentationprovided.
Warning:Switchoffpowersupply
Ensurethevessel’spowersupplyisswitchedOFFbefore
startingtoinstallthisproduct.DoNOTconnectordisconnect
equipmentwiththepowerswitchedon,unlessinstructedin
thisdocument.
Warning:Transducercables
Donotremovethetransducercablewhilsttheproductis
poweredon,doingsocancausesparks.Ifthetransducer
cableisaccidentlyremovedwhilsttheproductispoweredon,
switchtheproduct'spoweroff,replacethecableandthen
switchthepowerbackon.
W
arning:Sonaroperation
•NEVERtouchthetransducerfacewhenthesonaris
poweredon.
•SWIT
CHOFFthesonarifdiversarelikelytobewithin7.6m
(25ft)ofthetransducer.
Productwarnings
Warning:Maximumtransducercablelength
ThemaximumlengthofcablebetweenaRealVision™Max
3DtransducerandaMFD/sonarmodule(includingthe
transducer’scaptivecable)mustNOTexceed18m(59ft).
Cablelengthsgreaterthanthismaycausedamagetothe
RealVision™Max3DtransducerandMFD/sonarmodule.
Warning:Positivegroundsystems
Donotconnectthisunittoasystemwhichhaspositive
grounding.
Warning:Transduceroperation
Onlytestandoperatethetransducerinthewater.DoNOT
operateoutofwaterasoverheatingmayoccur.
Caution:Donotcuttransducercables
•Cuttingthetransducercableseverelyreducessonar
performance.Ifthecableiscut,itmustbereplaced,it
cannotberepaired.
•Cuttingthetransducercablewillvoidthewarrantyand
invalidatetheEuropeanCEmark.
Caution:Serviceandmaintenance
Thisproductcontainsnouserserviceablecomponents.Please
referallmaintenanceandrepairtoauthorizedRaymarine
dealers.Unauthorizedrepairmayaffectyourwarranty.
Importantinformation
7
