Item
Dimension
E
ThisdimensionisdependentonyourMFDvariant.R
eferto
yourMFDinstallationinstructions.
F
ThisdimensionisdependentonyourMFDvariant.R
eferto
yourMFDinstallationinstructions.
G
35.00mm(1.40in)
Note:
Forinstallationswherespacebehindthedisplayislimited,aright-angled
transducercableadaptorisavailable(A
80515).Usingtherightangled
cableadaptorwillreducedimensionEaboveby20mm(0.79in.)
