Raymarine SmartPilot X5 Installation & Setup Guide

Chapter 1: Installation and system overviews 3
Example SeaTalk system
SeaTalk allows connection of compatible instruments and equipment though a
dedicated data bus. This allows information sharing around the ships electronics
system.
Depth
transducer
GPS
ST60+ depth
instrument
SeaTalk
cable
SeaTalk
cable
SeaTalk or NMEA
SeaTalk
cable
SeaTalk
cable
SeaTalk cable, carries:
- 12V power from Course computer
- Data to and from Course computer
SeaTalk
cable
ST60+ speed
instrument
Course computer
ST6002
SmartController
Speed
transducer
SeaTalk
3-way block
D10628-1
ST6002
SmartController
12 V dc

Raymarine SmartPilot X5 Specifications

General

Brand	Raymarine
Model	SmartPilot X5
Category	Tiller
Language	English
