Page #15 background imageLoading...
Page #15 background image
7
Chapter 2: Installing the system
Before proceeding with the installation you should have the following to hand:
All necessary equipment and tools to install your SPX-5 Tiller system.
The correct type and length of power cable.
Schematic diagram detailing autopilot system location and connections.
You should also check that existing marine electronics, such as the GPS are installed
and working.
2.1 Installation precautions
CAUTION: Switch off power supply
Switch off the power supply before you start installing this product.
EMC installation guidelines
Raymarine equipment and accessories conform to the appropriate Electromagnetic
Compatibility (EMC) regulations. This minimizes electromagnetic interference
between equipment, which could otherwise affect the performance of your system.
Correct installation is required to ensure that EMC performance is not compromised.
For optimum EMC performance, we recommend that:
Raymarine equipment and the cables connected to it are:
i. At least 3 ft (1 m) from any equipment transmitting or cables carrying radio sig-
nals e.g. VHF radios, cables and antennas. In the case of SSB radios, the dis-
tance should be increased to 7 ft (2 m).
ii. More than 7 ft (2 m) from the path of a radar beam. A radar beam can normally
be assumed to spread 20 degrees above and below the radiating element.
The product is supplied from a separate battery from that used for engine start.
This is important to prevent erratic behavior and data loss which can occur if the
engine start does not have a separate battery.
Raymarine specified cables are used.
Cables are not cut or extended unless doing so is detailed in the installation
manual.
Remember
Where constraints on the installation prevent any of the above recommendations:
Always allow the maximum separation possible between different items of
electrical equipment. This will provide the best conditions for EMC performance
for the installation.
WARNING: Install at dockside
For safety reasons your boat must be at dockside before
commencing installation.
