Chapter 1: Installation and system overviews 5
Tools and equipment NOT supplied
You will need to supply the following equipment and tools:
Tools:
Drill
2.5 mm (
3
/
32
"), 6 mm(1/4"), 12.5 mm (1/2"), 18 mm (
23
/
32
") drill bits
Two-part epoxy (Araldite) adhesive
Cross-head/pozi-drive screwdriver
Slotted-head screwdriver
Cables / equipment
Power cable and fuse/breaker. See
page 19
.
Additional data cables (e.g. for connection of GPS or chartplotter)
Grounding braid. See
page 25
.
Accessories
The following accessories may be used to adapt the tiller drive mounting to suit
different installation requirements. See
Adapting the installation
on
page 16
.
Part Number Description
D001 Tiller Pin (package of 5)
D002 Mounting Socket (package of 5)
D003 Pushrod Extension 25 mm (1")
D004 Pushrod Extension 51 mm (2")
D005 Pushrod Extension 76 mm (3")
D006 Pushrod Extension 102 mm (4")
D007 Pushrod Extension 127 mm (5")
D009 Tiller Bracket 25 mm (1")
D010 Tiller Bracket 51 mm (2")
D011 Tiller Bracket 76 mm (3")
D014 Small threaded tiller pin 25 mm (1")
D014 Small Thread Tiller Pin (package of 5)
D020 Extra length tiller pin 71 mm (2.8”)
D021 Extra length threaded tiller pin 71 mm (2.8”)
D026 Pedestal Socket 38 mm (1.5")
D027 Pedestal Socket 51 mm (2")
D028 Pedestal Socket 64 mm (2.5")
