SPX-5 Tiller system specifications 63
Pilot Controller (ST6002)
Nominal supply voltage: 12 V DC via SeaTalk
Operating voltage range: 10 V to 15 V DC
Current consumption (in Standby
mode)
60 mA (less than 200 mA with full lighting)
Operating temperature: 0 °C to +70 °C (32 °F to 158 °F)
Water protection: waterproof to CFR46
Overall dimensions:
width
height
depth
110 mm (4.33 in)
115 mm (4.53 in)
41 mm (1.62 in)
Keypad: 8 button illuminated keypad
Liquid Crystal Display (LCD): shows heading, locked course and navigational data, and up
to 15 data pages
LCD illumination: 3 brightness levels + off
Input connections: SeaTalk (x2) and NMEA 0183
Output connections:
SeaTalk (x2)
EMC compliance: Europe 2004/108/EC (EMC)
Australia and New Zealand: C-Tick, Compliance Level 2
