14 SmartPilot X-5 Tiller & GP Tiller Installation & Setup Guide
.
25mm
(1.0 in)
D10706-1
620 mm (24.5 in)
4.
5.
6.
12.5 mm
(1/2 in)
Two part
epoxy adhesive
to fix mounting
socket in place
Dimension A
