Reboot RBM2000P - Setting Polarity for MIG Solid Wire; Connecting MIG Gun and Ground Clamp; Installing Wire Spool

Version Number: RBM2000P-20210517A1
11
2、 Set polarity for MIG Solid wire（gas).
With gas protection, solid wire welding, connect "P" with "+" in the figure below;
Gasless protection, flux-cored wire welding, connect "P" with "-" in the figure below.
3、Connect MIG gun and ground clamp.
solid wire welding Flux-cored wire Note: No need to use gas cylinder and gas meter
4、Install wire spool
0.030”(0.8mm)/0.040”(1.0mm)diameter
8”(200mm 5kg)wire spool
4”(100mm 1kg)wire spool
