11
PARAMETER
Time delay open >
Drive >
Entrance System >
Manual Control >
Control panel >
Locking >
LOCKING
Locking function 1
Lock type 1
Manual 0
Start delay 0
LOCKING FUNCTION
1 Night locked
3 Always locked
The default setting is “Always locked”
and an electric lock controlled by
terminals 20,21, & 22, will engage the
lock when the door is fully closed.
“Night locked” will engage the lock
only when the unit is turned off and
the Mechanical Control Panel is set
to either 9 Lock-A or 10 Lock-M; or
the “Display Panel / Keyboard” is set
to 0 - Locked mode. If no electric
lock is present, set to “1 Night locked”
for quicker opening.
With each of the Lock Types, the lock
relay (terminals 20,21,22) will switch
after operator actuation (terminals 2,
5, & 7), but before the operator starts
opening. Additionally, all except
“Magnet” will cause the unit to drive
closed slightly before opening.
Standard - relay opens @ full open;
Locking bolt & Magnet - relay opens
@ full closed;
Pulse - relay opens @ 10° open.
