Record 6100 Series - Page 13

13
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
Operation Mode >
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
Operation Mode >
PARAMETER
Input / Output >
CAN-BUS >
Miscellaneous >
Manual control >
Control panel >
Locking >
INPUT / OUTPUT
STG >
FEM 1 >
STG
AUX 1_IN 1
Ext. Sw IN 2
AUX 1_Out 1
If a BEA Bodyguard is
installed, this Parameter
should be set to “ 1 BEA
Bodyguard”, and terminal 9
should be connected to the
Data +Input of the BEA
Bodyguard. See the Series
6100&/or 8000 wiring
diagram. The next 3
settings are for CANBUS
programming of sensors
and are not used in North
America..
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
Operation Mode >
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
Operation Mode >
PARAMETER
Input / Output >
CAN-BUS >
Miscellaneous >
Manual control >
Control panel >
Locking >
INPUT / OUTPUT
STG >
FEM 1 >
FEM 1
FEM Type 0
Input >
Output >
FEM TYPE
0 Basic
1 Interlock
3 I/O-Set 1
For setting an Interlock
Function between 2
Operators; requires an
Expansion Module. Not
offered in the North America
currently.
Ext. Sw IN_F 2
Sequential
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
Operation Mode >
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
Operation Mode >
PARAMETER
Input / Output >
CAN-BUS >
Miscellaneous >
Manual control >
Control panel >
Locking >
INPUT / OUTPUT
STG >
FEM 1 >
STG
AUX 1_IN 1
Ext. Sw IN 2
AUX 1_Out 1
Ext. Sw IN_F 2
Sequential
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
Operation Mode >
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
Operation Mode >
PARAMETER
Input / Output >
CAN-BUS >
Miscellaneous >
Manual control >
Control panel >
Locking >
INPUT / OUTPUT
STG >
FEM 1 >
STG
AUX 1_IN 1
Ext. Sw IN 2
AUX 1_Out 1
Ext. Sw IN_F 2
Sequential
EXT. SW IN_F
0 disabled
1 Inactive by 1way
and locked
AUX1_OUT
0 disabled
1 BEA Bodyguard
2 Test sensors
5 Locked
7 Closed
Used in conjunction with
One Way or Locked mode
for disabling AKA (Exterior
Input)
4 Bell Control
AUX1_OUT
0 disabled
1 BEA Bodyguard
2 Test sensors
5 Locked
7 Closed
4 Bell Control
When selected and with a
noise maker attached to
this output, audible alarm
will sound for .6 seconds
every 10 seconds for those
with visual or sight
impairment when presence
detector signal is present
for a long time. Will sound
during a learn cycle also.
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
Operation Mode >
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
Operation Mode >
PARAMETER
Input / Output >
CAN-BUS >
Miscellaneous >
Manual control >
Control panel >
Locking >
INPUT / OUTPUT
STG >
FEM 1 >
STG
AUX 1_IN 1
Ext. Sw IN 2
AUX 1_Out 1
Ext. Sw IN_F 2
Sequential
SEQUENTIAL
0 Disabled
1 Seq. AKI/AKA
2 Seq. AKI
3 Seq. SSK
3 different input sets are
available. When Time
Delay is set high for
disabled persons, first
pulse opens the door. After
door is open next pulse
aborts hold open time and
closes door. Third pulse re-
opens door if door closes.
