Record 6100 Series - Entrance and Manual Control

Typically this parameter is automatically
set during initialization. With paired
operators (synchronous operation), it is
necessary to change jumper J14 on the
slave control from M1 to S1. When
changing this jumper, it is necessary to
reset the controls. Interlock configurations
not currently offered in North America.
7
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
Operation Mode >
PARAMETER
Driving cycle >
Time delay open >
Drive >
Entrance system >
Manual control >
Control panel >
ENTRANCE SYSTEM
Fire alarm 0
Control 0
Door type 1
Measure A 900
Measure G 2000
Interlock 0
DRIVE
Opening angle 40
Obstruction Close 20
Brake 0
Types of arms 0
Inverse 0
Obstruction Open 20
Measure A
900
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
Operation Mode >
PARAMETER
Driving cycle >
Time delay open >
Drive >
Entrance system >
Manual control >
Control panel >
ENTRANCE SYSTEM
Fire alarm 0
Control 0
Door type 1
Measure A 900
Measure G 2000
Interlock 0
DRIVE
Opening angle 40
Obstruction Close 20
Brake 0
Types of arms 0
Inverse 0
Obstruction Opn 20
Measure G
2000
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
Operation Mode >
PARAMETER
Driving cycle >
Time delay open >
Drive >
Entrance system >
Manual control >
Control panel >
ENTRANCE SYSTEM
Fire alarm 0
Control 0
Door type 1
Measure A 900
Measure G 2000
Interlock 0
CONTROL
0 Single control
1 Master control
2 Slave control
3 Master Interlock
4 Slave Interlock
Not currently used in the North
America.
Not currently used in the North
America.
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
Operation Mode >
PARAMETER
Driving cycle >
Time delay open >
Drive >
Entrance system >
Manual control >
Control panel >
ENTRANCE SYSTEM
Fire alarm 0
Control 0
Door type 1
Measure A 900
Measure G 2000
Interlock 0
Interlock
0 Disabled
1 All operation modes
2 Only one-way locked
Currently not used in the North
America.
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
SERVICE STG
Configure System >
Learning System >
Parameter >
Maintenance >
Functions >
Operation Mode >
PARAMETER
Driving cycle >
Time delay open >
Drive >
Entrance system >
Manual control >
Control panel >
ENTRANCE SYSTEM
Fire alarm 0
Control 0
Door type 1
Measure A 900
Measure G 2000
Interlock 0
DOOR TYPE
0 Basic operator
1 USA
25 USA Low Energy
26 EU Low Energy
29 UK
30 UK Low Energy
Typically set to either -
USA - for full power automatic operation
or
USA Low Energy - for units that will be
expected to be opened manually.
Note: In USA mode the unit will attempt
full control of the door position at all
times. Manually pushing the door, even
when fully closed, will be resisted with
force to maintain door position.
