MENU MAP
RED SCARLET
TM
TITLE:
3.2
REV
A
VERSION:
©2012 RED.COM, INC.
SCARLET-X
SHEET 2 OF 4
LOOK
USER
DEFAULT VALUES ARE DISPLAYED IN BOXES
FLOWCHART CONCEPT XL FILMS LTD.
FOCUS EXPOSURE PRESETS POWER
HDR
MEDIA SETTTINGS
DISPLAY
PROJECT AUDIO/VIDEO
SETUP
MAINTENANCE
GO TO SHEET 1 OF 4
TOOLS
ZEBRA
OVERLAY
MODES
FRAME GUIDE
AREA GUIDES
TOOLS OFF
EXPOSURE FOCUS
VIDEO
EDGE
ZEBRA 1
DISABLED BY DEFAULT
HIGH IRE
93 TO 109
108
LOW IRE
75 TO 107
99
TITLE GUIDE
ACTION GUIDE
COLOR
GAIN
FLUT®
COLOR/GAMMA
1.000
0.00 TO 4.0
SATURATION
0.000
-1.0 TO 1.0
CONTRAST
0.000
-10.0 TO 10.0
BRIGHTNESS
SECONDARY MENUS
PRESS MENU ICON (LCD) OR MENU BUTTON TO ACCESS
GO TO SHEET 1 OF 4
GO TO SHEET 3 OF 4
MONITOR
ZEBRA 2
DISABLED BY DEFAULT
HIGH IRE
1 TO 99
47
LOW IRE
0 TO 84
44
SHOW:
File Name
Time Code
AF Zones
Grid
TRANSPARANCY % / COLOR:
Lens Info
Center
Look Around:
APERTURE
1/4 F# / 1/3 F#
1/3 F#
FOCAL DISTANCE
METRIC IMPERIAL
Imperial
EXPOSURE
TIME / ANGLE
Time
SHUTTER MODE
ABSOLUTE RELATIVE
Absolute
SIZE
OFF
FULL
4:3
Full
TRANSPARENCY
0 / 25 / 50 / 75 / 100%
50%
2.4:1
USER
16:9
1.85:1
1.9:1
COLOR
WHITE
GRAY
TEAL
White
BLUE
RED
BLACK
PURPLE
YELLOW
GREEN
ASPECT RATIO
1.00 TO 10.00
2.40
1.00
+-+-
:
1.00 TO 10.00
SCALE / OFFSETS X / Y
X = 0.0% TO 100.0%
100.0% / 0.0%
100.0% / 0.0%
+-+-
Y = 0.0% TO 100.0%
ASPECT RATIO
OFF
16:9
14:9
Off
TRANSPARENCY
0 / 25 / 50 / 75 / 100%
50%
1.85:1
USER
4:3
2.4:1
COLOR
WHITE
GRAY
TEAL
White
BLUE
RED
BLACK
PURPLE
YELLOW
GREEN
ASPECT RATIO
Off
TRANSPARENCY
0 / 25 / 50 / 75 / 100%
50%
COLOR
WHITE
GRAY
TEAL
White
BLUE
RED
BLACK
PURPLE
YELLOW
GREEN
OFF
16:9
14:9
1.85:1
USER
4:3
2.4:1
1.000
0.0 TO 10.0
RED
1.000
0.0 TO 10.0
GREEN
1.000
0.0 TO 10.0
BLUE
0.000
-8.0 TO 8.0
FLUT
0.000
-7.0 TO 7.0
EXPOSURE
0.000
-2.0 TO 2.0
SHADOW
REDGamma3
REDGamma2
REDGamma3
SPACE / GAMMA
RAW
USER SCALE X / Y
X = 0.0% TO 100.0%
80.0% 80.0% +-+-
Y = 0.0% TO 100.0%
USER SCALE / OFFSETS X / Y
X = 0.0% TO 100.0%
100.0% / 0.0% 100.0% / 0.0% +-+-
Y = 0.0% TO 100.0%
TOUCH GESTURES:
Pinch to Magnify
Double-Click Right 25% to Record
Double-Click Left 25% to Start AF
LCD/EVF BRIGHTNESS
OFF
GO TO SHEET 4 OF 4
MAGNIFY
TOGGLE MAGNIFY 1:1
LINE STYLE
SOLID/DASHED/BRACKET
Bracket
Enable User Curve
BLACK/TOE/CENTER/KNEE/WHITE X / Y
X = 0.00 TO 1.00
0.00/0.25/0.50/0.75/1.00 +-+-
Y = 0.00 TO 1.00
0.00/0.25/0.50/0.75/1.00
ENABLE USER
CURVE
Dimensions:
LINE STYLE
SOLID/DASHED/BRACKET
Bracket
PLAYBACK
REDLogFilm
To Next Page
