Redball 680 - Page 95

11-01
680 High Clearance Sprayer - Parts & Schematics
Section F
1 6400-6-8 Hyd. Adapter, 3/8JIC & 3/4ORB Male 2
2 8010-15P Hyd. Quick Coupler, Univ. Poppet 2
3 K256 2” x 20” Welded Cylinder 2
4 645215 3” x 10” Cylinder 2
5 20TD12-112 2” x 12” Cylinder (60’ Boom) 2
645216 3” x 12” Cylinder (90’ Boom)
6 645214 3” x 12” Rephasing 1
7 645213 2 3/4” x 12” Rephasing 1
8 302-437 Hydraulic Valve; Directional Block 1
302-405 Hydraulic Valve; Directional Block (Rigid)
9 063-0172-111 Switch Box; Live Directional 1
10 6801-6-8R.03 Hydraulic Restrictor Elbow 14
11 004061 68’ Hyd. Hose 3
12 004051 77’ Hyd. Hose 1
13 004058 270’ Hyd. Hose (60’ Boom) 4
004653 330’ Hyd. Hose (90’ Boom)
14 004056 152’ Hyd. Hose 2
15 004060 39’ Hyd. Hose 1
16 6801-8R.03 Hydraulic Restrictor Elbow 2
17 004053 140” Hyd. Hose 2
18 004050 34” Hyd. Hose 1
19 007609 360” Hyd. Hose 2
004051 77' Hyd. Hose (3-Pt. Units)
20 007475 34” Hyd. Hose, 1/2” Female JIC Swiv
21* 210-127 Plug; -6 Outlet Plug 2
22* 210-038 Plug; -8 Cartridge Port 2
23* 12' Extension Harness 1
Item# Part # Description Quantity
Description: Hydraulic Boom Control Routing
44
Section F
