10 | P36E-10 Zero Clearance Direct Vent Gas Fireplace
|
10
installation
The clearances listed below are Minimum distances unless otherwise stated:
A major cause of chimney related res is failure to maintain required clearances (air space) to combustible materials. It is of the greatest
importance that this replace and vent system be installed only in accordance with these instructions.
Clearance to Combustibles from:
Back 0" (0mm)
Side 0" (0mm)
Floor 0" (0mm)
NOTE: The minimum oor clearance must be maintained from the top surface of the carpeting, tile, etc.
Minimum Clearance from Top of Unit to:
Ceiling from top of unit. 32" (1016mm)
Side Wall Clearances: 6"* (152mm)
* Measured from edge of unit. See the "Regency Clearances for dimensions" section.
Horizontal Vent Clearances:
Top 2" (51mm)
Side 1-1/2" (38mm)
Bottom 1-1/2" (38mm)
Vertical Vent Clearances 1-1/4" (32mm)
Alcove Clearances**:
Max. Depth 36" (914mm)
Min. Width 48" (1219mm)
Min. Height 72" (1829mm)
The HeatWave Duct Kit and the Heat
Release Kit have dierent clearance
and framing requirements, check the
HeatWave and Heat Release manual
for details.
Heat Release Kit
CLEARANCES
WARNING: Fire hazard is an extreme risk if these clearances are not adhered to.
