Reliance 7900 - Room Switch (ROOM); Room down Switch; Room up Switch; Lamp Switch (LAMP)

WARNING- THE MAIN OUTLET LOCATED ON
THE BACK OF THE CONSOLE OR BASE CAP
MARKED “PROJ” IS INTENDED TO SUPPLY
POWER TO A PROJECTOR OR SIMILAR
MEDICAL DEVICE COMPLYING WITH IEC
60601-1. ONCE CONNECTED, RESULTING
LEAKAGE CURRENTS MUST COMPLY WITH
IEC 60601-1-1 FOR MEDICAL ELECTRICAL
(ME) SYSTEMS. DO NOT CONNECT UNAU-
THORIZED DEVICES.
AVERTISSEMENT : LA PRISE DE COURANT
SITUÉE À L’ARRIÈRE DE LA CONSOLE OU
DU COUVERCLE DE LA BASE MARQUÉE
« PROJ » EST CONÇUE POUR FOURNIR
L’ALIMENTATION À UN PROJECTEUR OU
AUTRE APPAREIL MÉDICAL SIMILAIRE
CONFORME AVEC IEC 60601-1. UNE FOIS
L’APPAREIL CONNECTÉ, LES COURANTS
DE FUITE RÉSULTANTS DOIVENT ÊTRE
CONFORMES À IEC 60601-1-1 POUR LES
SYSTÈMES ÉLECTRIQUES MÉDICAUX. NE
CONNECTEZ PAS DE DISPOSITIFS NON
AUTORISÉS.
3.6.1.3. Room Switch (ROOM)
• Dual-Zone turns the ROOM Lights OFF or ON to a pre-
programmed intensity.
• Single-Zone turn ROOM Lights OFF or full ON.
3.6.1.4. Room Down Switch
• Decreases the intensity of the ALL room light(s).
3.6.1.5. Room Up Switch
• Increases the intensity of the ALL room lights(s).
3.6.1.6. Lamp Switch (LAMP)
• Turns the Overhead Lamp ON and OFF.
• Turns the lamp ON at 50% intensity when the switch is
pressed for the rst time after the system’s power cord
is plugged into the wall. Afterwards, the light will turn ON
at its previous intensity level..
• Turns the LAMP LED ON when power is applied to the
Overhead Lamp.
3.6.1.7. Lamp Down Switch
• Decreases the intensity of the Overhead Lamp.
3.6.1.8. Lamp Up Switch
• Increases the intensity of the Overhead Lamp.
3.6.1.9. Binding Post Switch (B/P)
• The B/P Switch is enabled when Switch 5 of SW2 is
turned OFF. See Table 1.
• When enabled, turns power to the binding Posts (Indirect
Ophthalmoscope) ON and OFF.
• Turns the B/P LED ON when power is applied to the
IN-7900
17
Ophthalmoscope.
• When disabled, the B/P Switch has no function. Power to
the Ophthalmoscope is controlled by the optional Indirect
Hanger Assembly.
3.6.1.10. B/P Down Switch
• De creases the intensity of the Indirect Ophthalmoscope.
3.6.1.11. B/P Up Switch
• Increases the intensity of the Indirect Ophthalmoscope.
3.6.1.12. Chair Base Up Switch
• Causes the Chair Base to raise.
3.6.1.13. Chair Base Down Switch
• Causes the Chair Base to lower
3.6.1.14. Auto Switch
• On a low voltage 980, 7000, 710 or FX920 Chair, this
switch causes the Chair Base to lower to its lowest
position and the Chair Top to move to its full upright
position.
Hanger Switch
• Affects the room lights and is programmable.
• See Switch 4 on Switchpack #2 in Section 2.4, Congur-
ing the System of this manual for details.
• See section 3.8.3 for Programming Instructions.
Slit Lamp Switch
• Affects the room lights and is programmable.
• See section 3.8.3 for Programming Instructions .
• See Switch 6 on Switchpack #1 in the Programming
Instructions Section of this manual for details.
• Push button at the beginning of Slit Lamp examination,
then push button again after examination is complete.
Well #1
• Controls room light(s) when the rechargeable instrument
is removed from well.
• When the instrument is returned to the well, the room lights
return to Scene #1. See section 3.8.3 for Programming
Instructions.
• See Switch 2 on Switchpack #1.
Well #2
• Controls room light(s) when the rechargeable instrument
is removed from the well.
• When the instrument is returned to the well, the room lights
return to Scene #1. See section 3.8.3 for Programming
Instructions.
• See Switch 3 on Switchpack #1.
