7. STORAGE REM - GRAINVAC VR12
7.2. P
LACING INTO STORAGE
88 9000-00-0042 R3
Figure 7.2 Inspection Door Open
Note: The inspection door is removed in Figure 7.2 for illustrative purposes only. Replace the
inspection door before operating the GrainVac.
4. Remove any residual material caught or hung up in the body of the GrainVac.
5. Inspect the condition of the drum. If the holes are plugged with debris or gummed
up, clean thoroughly. (It may be necessary to remove the drum completely to
remove all debris; refer to Section 6.6. on page 84). Replace the inspection door.
6. Open the clean-out door at the bottom of the auger and clean out all residual grain
left in the bottom (see Figure 7.3). The clean-out door should be left open so water
can drain out.
Figure 7.3 Auger Clean-Out Box
AUGER
CLEAN-OUT
HANDLE
AUGER
CLEAN-OUT
BOX
To Next Page
