RH850/U2A 292pin 2. Jumpers, Connectors and LEDs
R20UT4970ED0101 Rev.1.01 Page 16 of 67
July 08, 2022
Table 2.1 Jumpers overview (cont'd)
Jumper Function Remark
JP18 Marvell MDC – U2A P3_6
• JP18[2-1]: Connected
• JP18[OPEN]: Open
JP19 Marvel RxD2 Pull down
• JP19[2-1]: Connected
• JP19[OPEN]: Open
refer to 3.2 Voltage Distribution
JP20 Marvell RESETn - U2A AP0_8
• JP20[2-1]: Connected
• JP20[OPEN]: Open
JP22 For processor U2A16:
Voltage selection for GETH0RVCC
• JP22[2-1]: 5.0 V
• JP22[2-3]: 3.3 V
For processor U2A8/6:
Voltage selection for E0VCC (must be same as
JP6)
• JP22[2-1]: 5.0 V
• JP22[2-3]: 3.3 V
refer to 3.2 Voltage Distribution
JP23 Voltage selection for VDD
• JP23[2-1]: VDDs
• JP23[2-3]: SVR_OUTPUT
refer to 3.3 Device Core Voltage (VDD)
Selection
JP25
Voltage selection for Pull-up/Pull-down pin header
CN12 pins 1, 3, 5, 7, 9
• JP25[2-1]: 5.0 V
• JP25[2-3]: 3.3 V
refer to 6.4 Pull-Up/Pull-Down Pin Header
JP30
Current measurement bridge of 5.0 V A/D
Converter power supply
refer to 3.4 Current Measurement Bridges
JP31
Current measurement bridge of 3.3 V A/D
Converter power supply
refer to 3.4 Current Measurement Bridges
