Renesas RH850 User Manual

RH850/U2A 292pin 2. Jumpers, Connectors and LEDs
R20UT4970ED0101 Rev.1.01 Page 17 of 67
July 08, 2022
Table 2.1 Jumpers overview (cont'd)
Jumper Function Remark
JP32 Voltage selection for A0VCC
• JP32[2-1]: 5.0 V
• JP32[2-3]: 3.3 V
refer to 3.2 Voltage Distribution
JP33 Voltage selection for A0VREFH
• JP33[2-1]: 5.0 V
• JP33[2-3]: 3.3 V
refer to 3.2 Voltage Distribution
JP34 Voltage selection for A1VCC
• JP34[2-1]: 5.0 V
• JP34[2-3]: 3.3 V
refer to 3.2 Voltage Distribution
JP35 Voltage selection for A1VREFH
• JP35[2-1]: 5.0 V
• JP35[2-3]: 3.3 V
refer to 3.2 Voltage Distribution
JP36 Voltage selection for A2VCC
• JP36[2-1]: 5.0 V
• JP36[2-3]: 3.3 V
refer to 3.2 Voltage Distribution
JP37 Voltage selection for A2VREFH
• JP37[2-1]: 5.0 V
• JP37[2-3]: 3.3 V
refer to 3.2 Voltage Distribution
JP38 MODE0 level selection
• JP38[2-1]: H level
• JP38[2-3]: L level
refer to 6.1 Operation Mode Selection
JP39 FLMD1 level selection
• JP39[2-1]: H level
• JP39[OPEN]: L level
refer to 6.1 Operation Mode Selection
JP40 FLMD2 level selection
• JP40[2-1]: H level
• JP40[2-3]: L level
refer to 6.1 Operation Mode Selection
