Equator 300 safety information
13
1
2
3
4
5
6
7
8
9
11
10
12
14
15
15
1. Base casting with hand hold locations
2. SP25 probe assembly
3. Floating or moving platform
4. Support strut
5. Top casting
6. Drive strut
7. Counterbalance mechanism
8. Upper pivot / Hooke’s joint
9. Support arm for parallel constraint mechanism
10. CE marking and serial number
11. Drive housing
12. Parallel constraint mechanism
13. Fixture plate
14. Workpiece and fixture
15. Stop button and Button Interface, when fitted
