Renishaw Equator - Equator 500 Gauging System Components; Equator 500 Component Identification

14
Equator 500 gauging system specications
6
5
3
17
2
1
8
9
10
11
12
13
14
4
7
15
16
1. Base casting
2. SP25 probe assembly
3. Floating or moving platform
4. Support strut
5. Top casting
6. Drive strut
7. Counterbalance mechanism
8. Upper pivot and alignment bracket
9. Support arm for parallel constraint mechanism
10. CE marking and serial number
11. Drive housing
12. Parallel constraint mechanism
13. Fixture plate
14. Workpiece and fixture
15. Stop button and Button Interface, when fitted
16. Blanking cap / eye bolt
17. Equator Autojoint Adapter (EQ-AA1)
