43
Installation
When the Equator has been removed from its transit packaging according to the instructions attached to the
box, please follow the instructions in the following sections to start the system.
Equator machine positioning
• The Equator system needs to be placed on a flat and sturdy surface. It is advised that a 1 m diameter
clearance of other objects is established to avoid collisions.
• It is suggested that the monitor and the joystick (if fitted) are located near the machine so that operational
information can be seen by the operator.
Equator Controller positioning
• The controller can be placed on either side of the Equator as preferred. It can be placed either standing or
lying down.
• Ensure that the fan intakes at the front and outlets at the rear do not become blocked in any way. Allow
10 cm distance between fan intakes and outlets to any surface.
Connecting cables - Equator 300 ...................................................................................................................44
Connecting cables - Equator 500 ...................................................................................................................46
Connecting probe system - Equator 300 ........................................................................................................48
Connecting probe adaptor - Equator 500 .......................................................................................................50
Connecting probe system - Equator 500 ........................................................................................................51
Connecting styli ..............................................................................................................................................53
Downloading Equator license and Software Suite ..........................................................................................54
