W.4: Power outputs must not exceed these limits
• (P1) 24 V ± 3% 4 A
(MAX CONTINUOUS) 5 A (MAX PEAK)
• (P2) 48 V ± 3% 4 A
(MAX CONTINUOUS) 8 A (MAX PEAK)
• (P1 & P2) COMBINED (48 V & 24 V) CONTINUOUS POWER OUTPUT MUST BE LESS THAN 300 W
NOTE: Both Ethernet ports (LAN 1, LAN 2) cannot be connected to the same network.
