Programming Information
101
Doc No: UMAN\FL\0110
Rev. No.: 1.02B
System Register for Special Function Inputs and PWM outputs:
Register Description Register Number
Configuration Register for Special inputs MW10
Configuration Register for PWM output MW11
Single Phase Counter
Set Value
Channel 1 MW12, MW13
Channel 2 MW14, MW15
Count Value
Channel 1 MW16, MW17
Channel 2 MW18, MW19
Soft Gate (Device)
Channel 1 M 320
Channel 2 M 328
Interrupt Enable (Device)
Channel 1 M 322
Channel 2 M330
Count Preset (Device)
Channel 1 M323
Channel 2 M331
