Programming Information
102
Doc No: UMAN\FL\0110
Rev. No.: 1.02B
Register Description Register Number
Single Phase Speed Counter
Sampling Time
Channel 1 MW12
Channel 2 MW14
Hold Value
Channel 1 MW16, MW17
Channel 2 MW18, MW19
Soft Gate (Device)
Channel 1 M 320
Channel 2 M 328
Quadrature Bi Pulse
Comparision Value1 MW12, MW13
Comparision Value2 MW14, MW15
Count Value MW16, MW17
Soft Gate (Device) M320
Interrupt Enable1 (Device) M322
Count Preset 1 (Device) M324
Interrupt Enable 2 (Device) M323
Count Preset 2 (Device) M325
Pulse Output Function
Pulse Enable Flag (Device) M336
Frequency Setting Register MW22, MW23
Frequency Setting Error Flag (Device) M191
PWM Output Function
Pulse Enable Flag (Device) M336
Frequency Setting Register MW22, MW23
ON duty setting register MW24, MW25
pulse width error flag M189
On duty setting error flag M190
Frequency Setting Error Flag (Device) M191
System Coil for Debug Function
Register Description Register Number
S0000 Carry bit
S0021 Communication recover enable bit for port1
S0022 Communication recover enable bit for port2
S0034 Instruction error flag
