Renu Electronics FlexiLogics series - Page 59

Hardware
59
Doc No: UMAN\FL\0110
Rev. No.: 1.02B
FlexiLogics TO Toshiba T1 PLC (RC-P-019A-00)
FlexiLogics TO Toshiba T2 PLC (RC-P-019B-00)
FlexiLogics TO GE 90/30 PLC (RC-P-002-00)
PIN SIGNALS
8P8C(RJ45) MALE PIN-OUTS
(Unit End)
8 Pin MINIDIN MALE PIN-OUTS
(PLC End)
TXD
18
RXD
26
GND
3 5 (Connect to shield )
short pin4&7atPLCend
PIN SIGNALS
8P8C(RJ45) MALE PIN-OUTS
(Unit End)
DB9 MALE PIN-OUTS
(PLC End)
TXD
12
RXD
23
GND
3 5 (Connect to shield )
Short 7&8atPLCEnd
(DB9 End)
PIN SIGNALS
8P8C(RJ45) MALE PIN-OUTS
(Unit End)
DB15 MALE PIN-OUTS
(PLC End)
TX+
411
13
10
12
7
1
RX+
RX-
5
TX-
6
7
GND
Shield connect only
plc End
3
Short 8 & 14 on PLC end
Short 6 & 15 on PLC end
