Renu Electronics FlexiLogics series - Page 60

Hardware
60
Doc No: UMAN\FL\0110
Rev. No.: 1.02B
FlexiLogics TO Mitsubishi FX PLC (RC-P-008A-00)
FlexiLogics TO Aromat FP0 Series PLC (RC-P-015A-00)
FlexiLogics TO TSX 07 PLC (RC-P-026A-00)
PIN SIGNALS
8P8C(RJ45) MALE PIN-OUTS
(Unit End)
8 Pin MINIDIN MALE PIN-OUTS
(PLC End)
TX+
42
7
3
1
4
RX+
RX-
5
TX-
6
7
SG & SHIELD
3
PIN SIGNALS
8P8C(RJ45) MALE PIN-OUTS
(Unit End)
5 PIN MINIDIN MALE
PIN-OUTS (PLC End)
TXD
1
2
3
1
RXD
2
SG & SHIELD
3
PIN SIGNALS
8P8C(RJ45) MALE PIN-OUTS
(Unit End)
8 PIN MINIDIN MALE
PIN-OUTS (PLC End)
A
4&5
6&7
7
2
1
GND & SHIELD
B
3
FlexiLogics to A.B.Micrologix PLC(RC-P-027A-00)
PIN SIGNALS
8P8C(RJ45) MALE PIN-OUTS
(Unit End)
8 PIN MINIDIN MALE
PIN-OUTS (PLC End)
TXD
14
7
2
RXD
2
GND
(shield connect to
only PLC end)
3
