Configuration
79
Doc No: UMAN\FL\0110
Rev. No.: 1.02B
SW046 Ladder Scan Time Read only Value is multiple of 0.1 mSec
S0034 Ladder Instruction Error Read/Write Set if Division by zero operation is performed in
Status the ladder instruction and for invalid conditions or
operands in case of conversion instructions.
Configuration Words and coils
Register / Coil Tag Name Read / Write Description
MW0000 PLC Operation Mode Read/Write Bit0-3: 0: Initialization 1: HALT Mode 2: RUN
(Bit 0 to Bit 3) Mode 3: RUN-F Mode 4: HOLD Mode 6: ERROR
Mode.
MW0001 Error Register 1 Read Only Refer mapped coils M16 to M31
MW0002 Error Register 2 Read Only Refer mapped coils M32 to M47
MW0003 RUN/STOP Switch Control Read Only 1: HALT, 0: RUN. Only LSB is used. other bits (1
(Retentive) to 15) are not used.
MW0005 Digital Filter constant Read/Write Enabled when MW10 bit 16 is ON.
(0 to 15 mS)
MW0010 Configuration Register for Read/Write Refer Special input - output section
Special inputs
MW0011 Configuration Register for Read/Write Refer Special input - output section
PWM output
MW0012 Preset values for high Speed Read/Write Used to set the preset values for high speed
MW0013 Counter counter
MW0014
MW0015
MW0016 Count Values for high Speed Read/Write Preset count values of the high speed counters
MW0017 Counter are stored
MW0018
MW0019
MW0020 High Speed counter Read/Write Control flags for high speed counters
control flags
MW0021 Special output control flags Read/Write Refer Special input - output section
MW0022 Special Output Control Flags Read/Write Control flags for high speed counters
MW0023
MW0024 Special output Frequency Read/Write Refer Special input - output section
MW0025 Setting
MW0030 System Timer Coils Read Only Refer mapped coils M00480 to M00487
MW0031 User Interrupt program Status Read Only Bit 0 for timer ,Bit 1 for IO1, Bit 2 for IO2. Refer
Flags mapped coils M496,M497 & M498
when MW10 bit 16 is ON.
MW0033 Unit IP Address Lo Word Read Only Used for Ethernet Model
MW0034 Unit IP Address Hi Word Read Only
MW0035 Unit Subnet Mask Address Read Only
Lo Word
MW0036 Unit Subnet Mask Address Read Only
Hi Word
MW0037 Unit Default Gateway Read Only
Lo Word
MW0038 Unit Default Gateway Read Only
Hi Word
M00016 CPU error Read Only ON at error state
M00017 I/O error Read Only ON at error state
M00018 Program error Read Only ON at error state. This group includes Laader
Scan time.
