Configuration
82
Doc No: UMAN\FL\0110
Rev. No.: 1.02B
FLA0402U:
Sr. No. Description Register Type
1 Input Channel 1 Data XWxx00 R
2 Input Channel 2 Data XWxx01 R
3 Input Channel 3 Data XWxx02 R
4 Input Channel 4 Data XWxx03 R
5 Output Channel 1 Data YWxx00 R/W
6 Output Channel 2 Data YWxx01 R/W
7 Input Channel 1 Type Select MWxx06 R/W
8 Input Channel 2 Type Select MWxx10 R/W
9 Input Channel 3 Type Select MWxx14 R/W
10 Input Channel 4 Type Select MWxx18 R/W
11 Output Channel 1 Type Select MWxx22 R/W
12 Output Channel 2 Type Select MWxx26 R/W
13 Input and Output Conversion MWxx30 R/W
Enable
14 Reserved MWxx31 -
15 Reserved MWxx32 -
16 Reserved MWxx33 -
17 Reserved MWxx34 -
18 Reserved MWxx35 -
FLA0004:
Sr. No. Description Register Type
1 Output Channel 1 Data YWxx00 R/W
2 Output Channel 2 Data YWxx01 R/W
3 Output Channel 3 Data YWxx02 R/W
4 Output Channel 4 Data YWxx03 R/W
5 Output Channel 1 Type Select MWxx04 R/W
6 Output Channel 2 Type Select MWxx08 R/W
7 Output Channel 3 Type Select MWxx12 R/W
8 Output Channel 4 Type Select MWxx16 R/W
9 Output Conversion Enable MWxx20 R/W
