Configuration
83
Doc No: UMAN\FL\0110
Rev. No.: 1.02B
Channel Type Selection Values Table:
Use the following values in the Input and output channel type select register to configure the corresponding channel
to particular type.
e.g. If you want to configure the Input channel 3 of FLA0800L model as ( 0 – 10 V ) type, then move value 19 in
MWxx16 configuration register. Here xx digital denotes the slot number in which the FLA0800L model is connected
to PLC. The Conversion Enable Flag should be one to start the conversion (A to D or D to A).
Input Channel Type Value
Not Defined 0
mV( 0 - 100 mV ) 1
mV( 0 - 50 mV ) 3
mA( 0 - 20mA ) 5
mA( 4 - 20mA ) 7
Voltage ( 0 - 10V ) 19
Voltage ( 1 - 5V ) 20
RTD PT-100 (alpha1) 9
RTD PT-100 (alpha2) 10
RTD PT-1000 21
Thermocouple (B-Type) 11
Thermocouple (R-Type) 12
Thermocouple (S-Type) 13
Thermocouple (E-Type) 14
Thermocouple (J-Type) 15
Thermocouple (K-Type) 16
Thermocouple (N-Type) 17
Thermocouple (T-Type) 18
Output Channel Type Value
Not Defined 0
mA( 4 - 20mA ) 1
Voltage ( 0 - 10V ) 2
