Special Input and Output
87
Doc No: UMAN\FL\0110
Rev. No.: 1.02B
The Mode selection is done through two registers as below.
Configuration Register 10 (High Speed Input): ( MW0010).
PWM Output Function
Pulse Enable Flag (Device) M336
Frequency Setting Register MW22, MW23
ON duty setting register MW24, MW25
pulse width error flag M189
On duty setting error flag M190
Frequency Setting Error Flag (Device) M191
FEDCBA9876543210
0000
000: Normal
001: Ch2INT
010: Ch2HSC
011: Quadrature
100: Ch2 Single
phase counter
000: Normal
001: Ch1INT
010: Ch1HSC
011: Quadrature
100: Ch1 Single
phase counter
0: INT1 Rising
1: INT1 Falling
0: INT2 Rising
1: INT2 Falling
Channel1 HSC (Adding Counter)
0: Single Phase Up Counter
1: Single Phase Down Counter
Channel2 HSC (Adding Counter)
0: Single Phase Up Counter
1: Single Phase Down Counter
Quadrature
00: 1X mode
01: 2X mode
10: 4X Mode
Reserved
0: Variable input filter disable
1: Variable input filter enable
To Next Page
