The Astral device
6
Description
7
DC power inlet
8
Device on/off push button
9
SpO
2
Sensor connector
10
Remote alarm five pin connector
11
Low flow oxygen input (up to 30 L/min)
12
Air inlet (complete with hypoallergenic filter)
The Astral device interface
The interface of the Astral device comprises several different features described in the following image.
Description
1
Touch screen
2
Power source indicators
AC (mains power supply)
DC (external battery or car accessory adapter or RPSII)
Internal battery
3
Therapy on/off indicator
Device ready
Constant green display when the device is turned on but not ventilating.
