Chapter 5
5-10 BiPAP Focus Ventilator Service Manual © Respironics, Inc. REF 1029568 Rev B
Diagnostic Mode and Troubleshooting
Figure 5-8: Entering a Name for the Connection to the BiPAP Focus Ventilator
5. Select the appropriate serial port from the Connect using: drop-down
list (Figure 5-9 shows COM1), then click OK.
Figure 5-9: Selecting the Serial Port
6. Enter these settings for the serial port (Figure 5-10), then click OK.
Figure 5-10: Serial Port Settings
19200 Bits per second
8 Data bits
Parity = None
1 Stop bit
Flow control = None
