Chapter 5
Diagnostic Mode and Troubleshooting
REF 1029568 Rev B BiPAP Focus Ventilator Service Manual © Respironics, Inc. 5-11
7. The blank HyperTerminal window remains. Continue configuring the
properties. Click File > Properties from the menu bar.
8. Click on the Settings tab (Figure 5-11).
9. Select ANSIW from the Emulation drop-down list box.
Figure 5-11: HyperTerminal Settings Tab
10. Click the Terminal Setup button.
11. Select underline and blink for cursor settings then click OK.
Figure 5-12: Terminal Settings
12. Click the ASCII Setup button (Figure 5-11).
