Diagnostic Mode and Troubleshooting
905 Pwr On reset 6/13/09 16:32
300 POST Successful 6/13/09 16:32
102 Power Off 6/13/09 16:32
639 Disconnect 6/13/09 16:31
905 Pwr On reset 6/13/09 16:27
300 POST Successful 6/13/09 16:27
9. Once HyperTerminal displays the DRPT in the main window, click
Transfer > Capture Text > Stop to finish capturing text to the text file.
NOTE: The DRPT capture file is a TXT file by default: use any word processing
program to view the file.
Figure 5-14 shows how to interpret each line of the DRPT report.
Figure 5-14: Interpreting the DRPT Report
NOTE: The last two fields (if applicable) can also show mode/setting changes
and their from/to values.
10. To save the DRPT, highlight the appropriate fields (or Edit>Select All),
copy (Edit>Copy) and then paste into any text editor/word processing/
email program.
437 Battery Voltage Failed 6/19/09 20:42 V 615,615
437 - diagnostic Code
Battery Voltage Failed - description
6/19/09 - MM/DD/YY
20:42 - Time stamp of occurrence
615, 615 - previous
and current values
V or T - System errors
V= voltage, T= temperature
(if applicable)
