Technical Data
12
Example 2:
Feed material:
Limestone (< 5 mm)
Bottom sieve:
0.5 mm
Speed:
5 000 rpm
At these operating conditions, the workplace related equivalent continuous sound level
L
eq
= 72.8 dB(A).
Example 3:
Feed material:
Limestone (< 5 mm)
Bottom sieve:
0.5 mm
Speed:
10 000 rpm
At these operating conditions, the workplace related equivalent continuous sound level
L
eq
= 77.2 dB(A).
3.4 Electromagnetic Compatibility (EMC)
 EMC class according to DIN EN 55011: B
3.5 Rated Power
~ 2 500 W (VA)
3.6 Motor Rotation Speed
 Rated motor rotation speed: 3 000 – 10 000 revolutions per minute (rpm).
 Adjustable in increments of 500 rpm.
In order to reduce the heating of the grinding material caused by high friction forces at high
speeds, a distance rotor can be used for the grinding of heat-sensitive products.
3.7 Dimensions and Weight
All specifications, unless otherwise stated, include the optional base frame.
 Height: 1 200 mm
 Height incl. vibratory feeder DR 100: ~ 1 450 mm
 Width: 580 mm
 Width incl. cyclone separator: 930 mm
 Depth: 700 mm
 Weight: ~ 60 kg
 Weight without base frame: ~ 50 kg
