Falling down of the device
Incorrect positioning or insufficient working space
Due to its weight, the device can inflict personal injury if it falls down.
The device must, when used as table-top device, only be operated on
a sufficiently large, strong and stable workplace.
The device must, when used as table-top device, be firmly screwed
to the working surface.
Width with open door: ~ 740 mm
Depth with open door: ~ 640 mm
Width of the base: 940 mm (without cyclone separator)
1 130 mm (with cyclone separator)
Depth of the base: 740 mm (without base frame)
800 mm (with base frame)
Location requirements:
When used as table-top device, the device must be bolted to a vibration-free, plane, stable and
free surface. When used as floor-standing device (mounted on the optional base frame), the
device must be placed on a level base and secured against rolling away.
3.9 Receptacle Volume
The receptacle volume (feed volume) depends on the sample material and the collecting
receptacle used.
Feed volume: < 5 l (with 5 l collecting receptacle)
max. 26 l (with 30 l collecting receptacle)
3.10 Feed Grain Size
Feed grain size: ≤ 25 mm
3.11 Suitable Sieve Diameters
Trapezoidal perforation: 0.08 mm / 0.12 mm / 0.20 mm / 0.25 mm / 0.35 mm / 0.50 mm /
0.75 mm / 1.00 mm / 1.25 mm / 1.50 mm / 2.00 mm
Round perforation: 3.00 mm / 4.00 mm / 10.00 mm
All sieve inserts are available as 360° sieve insert (ring sieve), as well as 180° sieve insert. The
360° sieve inserts are particularly suitable for the grinding of soft and brittle materials. To
achieve an additional size reduction effect through impact, a 180° grinding insert can be used
together with a 180° sieve insert for medium-hard materials.
