Retsch SR 300 - Setting up as Table-top Device

First Commissioning
19
5.1 Setting up as Table-top Device
Fig. 3: Removing the transport profiles
 Loosen the four hexagon socket head screws (SC) to remove the transport profiles (TP) from
the SR 300.
 Position the SR 300 on the designated table as close as possible to the front edge of the
table. Make sure that the discharge flange (AF) for the sample receptacle does not touch the
edge of the table.
NOTICE The table must be designed for the weight of approx. 50 kg of the SR 300!
Furthermore, the table must be plane, stable and vibration free!
AF
TP
SC
