Fig. 37: Rear side of the vibratory feeder DR 100
Plug the power cable into the mains connection on the rear.
Set the operating mode selector switch (DR3) to "Standard". A control via "Extern" (external)
is not possible in conjunction with the SR 300.
Turn on the vibratory feeder DR 100 via the rear mains switch (DR4).
For detailed information on the controls, please refer to the manual of the vibratory feeder
DR 100.
11.2 Cyclone Separator
Serious personal injury
Intervention in rotating rotor
Unintentional intervention in the grinding chamber and the rotating rotor
can sever fingers and cause serious hand injuries.
The power cable must be unplugged before removing the discharge
flange.
Never operate the device without mounted discharge flange.
