Emergency unlocking
Drive continuing to run
Substantial risk of injury due to the drive and associated device parts
running on a long time without being braked!
Activate the emergency unlocking only when the device has come to
a complete stop and when disconnected from the mains supply.
The emergency unlocking is used for manual unlocking of the electrical locking mechanism in
the event of a power failure. To open the door, the mechanical locking mechanism must also be
opened by pulling the catch mechanism (J) and turning the locking lever (H).
Fig. 16: Position of the emergency unlocking
Remove the protective cap (NE1) on the right side of the device.
Insert the supplied hexagon socket wrench (NE2) into the lateral opening.
Fig. 17: Emergency unlocking of the device
