①
: Detailed descriptions on (-) and (+) in the Operating Instructions must be
read through and followed before any operation on these two terminals.
Fig. 2-4: Grounding and PE terminals
1. Grounding terminal for mains cables
2. Reserved for PE / shielding adapter (Order additionally)
3. Reserved for PE / shielding adapter (Order additionally)
4. Grounding terminal for motor cables
EFC 3610 / EFC 5610 Bosch Rexroth AG
Electric Installation
DOK-RCON03-EFC-X610***-QU11-EN-P
19/87
