REXROTH EFC 3610 Series Quick Start Guide

3.4.3 Group C: Power Parameters
C0: Power control parameters
Code Name Setting range Default Min. Attri.
C0.00
Control mode
(EFC 5610 only)
0: V/f control
1: Sensorless vector con-
trol
2: Vector control with en-
coder (only for EFC5610)
0 – Stop
C0.01
Normal / Heavy duty
setting
①
0: ND (Normal duty)
1: HD (Heavy duty)
1 – Stop
C0.05 Carrier frequency
0K40...22K0: 1...15 kHz
30K0...132K: 1...12 kHz
0K40...4K00: 6k
5K50...22K0 (HD): 6k
5K50...22K0 (ND): 4k
30K0...90K0: 4k
110K...132K: 2k
1 Run
C0.06
Carrier frequency
automatic adjustment
0: Inactive
1: Active
1 – Stop
C0.10
Automatic voltage sta-
bilization
0: Always active
1: Always inactive
2: Inactive only during de-
celeration
0 1 Stop
C0.15
Brake chopper start
voltage
②
1P 200 VAC: 300...390 V 385
1 Stop
3P 400 VAC: 600...785 V 770
C0.16
Brake chopper duty cy-
cle
②
1...100 % 100 1 Stop
C0.24
Stall overvoltage hyste-
resis voltage
0...100 V
1P: 30
1 Stop
3P: 50
C0.25
Overvoltage prevention
mode
0...3 3 – Stop
C0.26
Stall overvoltage
prevention level
1P 200 VAC: 300...390 V 385
1 Stop
3P 400 VAC: 600...785 V 770
C0.27
Stall overcurrent
prevention level
③
20.0 %...[C2.42] 150.0 0.1 Stop
C0.28
Phase loss protection
mode
0...3 3 – Run
C0.29
Converter overload
pre-warning level
20.0...200.0 % 110.0 0.1 Stop
EFC 3610 / EFC 5610 Bosch Rexroth AG
Start-up
DOK-RCON03-EFC-X610***-QU11-EN-P
41/87
