1 Mechanical Installation
1.1 Visual Check
After unpacking the frequency converter, perform a thorough visual check.
Check the following:
● The right device has been supplied
● The device has no damage
● No transport damage such as scratches, cracks or dents
If you find any deviation from one of the above points, please contact your
Bosch Rexroth sales partner.
1.2 Ambient Conditions
If it is to function perfectly, the frequency converter must be installed in an envi-
ronment matching the data provided below.
Rated ambient temperature -10...45 °C
Derating / ambient temperature 1.5 % / 1 °C (45...55 °C)
Rated altitude ≤ 1,000 m
Derating / altitude 1 % / 100 m (1,000...4,000 m)
Relative humidity ≤ 90 % (No condensation)
Degrees of protection IP 20 (Control cabinet mounting)
Degrees of pollution 2 (EN 50178)
Tab. 1-1: Ambient conditions
EFC 3610 / EFC 5610 Bosch Rexroth AG
Mechanical Installation
DOK-RCON03-EFC-X610***-QU11-EN-P
1/87
