3.4.7 Group U: Panel Parameters
U0: General panel parameters
Code Name Setting range Default Min. Attri.
U0.00 Direction control by panel 0: Forward; 1: Reverse 0 – Run
U0.01 Stop button control
0: Active only for panel control
1: Valid for all control methods
1 – Run
U0.99 Panel firmware version 00.00...99.99 – 0.01 Read
U1: LED panel parameters
Code Name Setting range Default Min. Attri.
U1.00 Run monitoring display
0...99
0 – Run
U1.10 Stop monitoring display 2 – Run
0: Output frequency; 1: Actual speed
2: Setting frequency; 3: Setting speed
4: User-defined setting speed; 5: User-defined actual speed
9: V/f separation setting voltage; 10: Output voltage; 11: Output current
12: Output power; 13: DC-bus voltage
14: Energy saving counter kWh; 15: Energy saving counter MWh
16: Output torque; 17: Setting torque
20: Power module temperature; 21: Actual carrier frequency
23: Power stage running time; 30: AI1 input
31: AI2 input; 33: I/O card EAI1 input; 34: I/O card EAI2 input
35: AO1 output; 37: I/O card EAO output
40: Digital input 1; 43: I/O card digital input
45: DO1 output; 47: I/O card EDO1 output; 48: I/O card EDO2 output
50: Pulse input frequency; 55: Pulse output frequency
60: Relay output; 62: I/O card relay output
63: Relay card output; 70: PID reference engineering value
71: PID feedback engineering value; 80: ASF Display00
81: ASF Display01; 82: ASF Display02
83: ASF Display03; 84: ASF Display04
85: ASF Display05; 86: ASF Display06
87: ASF Display07; 88: ASF Display08; 89: ASF Display09
98: High resolution output current; 99: Firmware version
Bosch Rexroth AG
Start-up
EFC 3610 / EFC 5610
78/87
DOK-RCON03-EFC-X610***-QU11-EN-P
