REXROTH EFC 3610 Series Quick Start Guide

U2: LCD panel parameters
Code Name Setting range Default Min. Attri.
U2.01 Backlight mode setting
0: Energy saving
1: Always on
1 – Run
U2.02 Panel lock setting
0: Unlock
1: Lock
0 – Run
U2.03 Remote / Local setting
0: Remote
1: Local
0 – Stop
U2.04 Language selection
0: English
1: Chinese
2: Germany
3: French
4: Russian
5: Spanish
6: Portugal
7: Italian
8: Korean
0 – Stop
U2.09 Permanent monitoring
0...99
0 – Run
U2.10 Run monitoring items 1 0 – Run
U2.20 Stop monitoring items 1 0 – Run
U2.11 Run monitoring items 2
0...100
2 – Run
U2.12 Run monitoring items 3 11 – Run
U2.13 Run monitoring items 4 13 – Run
U2.14 Run monitoring items 5 16 – Run
U2.15 Run monitoring items 6 17 – Run
U2.21 Stop monitoring items 2 2 – Run
U2.22 Stop monitoring items 3 11 – Run
U2.23 Stop monitoring items 4 13 – Run
U2.24 Stop monitoring items 5 16 – Run
U2.25 Stop monitoring items 6 17 – Run
Setting range of U2.09...U2.25:
0: Actual output frequency; 1: Actual speed
2: Setting frequency; 3: Setting speed
4: User-defined setting speed; 5: User-defined output speed
9: V/f separation setting voltage; 10: Output voltage; 11: Output current
12: Output power; 13: DC-bus voltage
EFC 3610 / EFC 5610
Bosch Rexroth AG
Start-up
DOK-RCON03-EFC-X610***-QU11-EN-P
79/87
